Induced polarization effect in time-domain electromagnetic prospecting, noise or signal?


Enroll In Pro Plan

Session 1, Monday, September 9, 2019, 5 pm to 6 pm Cairo time (10:00 am to 11:00 am, US Central Time)

Session 2, Monday September 30, 2019, 5 pm to 6 pm Cairo time (10:00 am to 11:00 am, US Central Time)

Two live sessions are completed. Please view the videos from the recordings below.

About the Course

SEG members, view the course for free!

2019 SEG Virtual Honorary Lecture Middle East and Africa. Inductive electromagnetic methods are commonly used to map the distribution of subsurface conductive materials. On the other hand, the galvanic induced polarization method is very effective in mapping polarizable materials (having high chargeability). Chargeable or polarizable materials act like capacitors and become electrically polarized under the influence of an electric field. When the applied current is switched off (or the induced current decays), the accumulated charges relax back to their original unpolarized state. This results in a net flow of current (called polarization current) in the opposite direction of the induced primary current flow. The most common way of characterizing the complex resistivity of the ground is with the Cole-Cole model parameters: the chargeability ( m), the decay rate of the polarization ( τ), the frequency dependent exponent (c) and dc resistivity (ρ). This phenomenon normally manifests itself in time-domain (transient) electromagnetic data as negative amplitudes or sign reversal. These negative sign reversals have been recorded since the 1970s or earlier in ground TEM data, and in airborne TEM data since the 1990s primarily using central or coincident receiver configurations. However, for many years the negative transients were considered as undesirable or noisy data by many practicing geophysicists, and were eliminated from their field data because there existed no convenient method of inverting the data to extract useful parameters. Hence geophysicists were forced to throw away valuable data that contains information on the electrical properties of the polarizable earth material being surveyed such as economic minerals including disseminated sulfides, gold and kimberlite pipes. Recently, this has been changed, and since the turn of the century, many serious attempts have been made to model and invert the Cole-Cole parameters from the measured ground and airborne TEM data showing negative transients.

This lecture emphasizes the importance of inductive negative transients. It also describes how we may use them, together with the early-time positive transients, to infer details of the distribution of conductive and chargeable materials in the subsurface especially in the conditions where galvanic induced polarization measurement are not effective as in environments with extremely resistive overburdens, where galvanic contact is not practical. However, in order to have a reliable model of the subsurface polarizable targets, it is important to make use of both phenomena (galvanic and inductive) through joint inversion, which provide complementary information as a function of depth and measurement time scales.

Your Instructor

Hesham El-Kaliouby, PhD, SEG-HL
Hesham El-Kaliouby, PhD, SEG-HL

Hesham El-Kaliouby is a professor of geophysics at the National Research Center in Egypt and is currently serving as the chair of the Geophysics department.

El-Kaliouby used to work as an associate professor at the Sultan Qaboos University, Oman (2012– 2016). He also worked as a consultant in geophysics for the Saudi Geological Survey, Saudi Arabia (2011–2012) and a senior research associate at Lancaster University, UK (2009–2011). Prior to this he was an associate professor at King Abdulaziz University, Saudi Arabia (2005–2009). El-Kaliouby also worked as a postdoctoral researcher for the University of Arizona (2002–2004).

His research interests involve electric and electromagnetic methods for geologic, hydrogeologic, engineering, and mining applications. He also is interested in forward and inverse modeling techniques and the electrical properties of rocks on lab and field scales. He published many papers in top tier Journals and conferences. He also act as reviewer for many top ranked Journals.

El-Kaliouby is an Active member of the Society of Exploration Geophysicists (SEG). He joined SEG in 1985 as a student member. He served as student alumni committee member (1999–2000) and as the faculty adviser of Sultan Qaboos University SEG student chapter (2012–2016).

El-Kaliouby was selected as the first EAGE student lecturer for Africa in 2017 through the Student Lecture Tour program.

El-Kaliouby holds a bachelor‘s (honor) degree (1987) and master‘s degree (1995) in geophysics, both from Cairo University, Egypt. He received his PhD in geophysics (2001) from Cairo University through a joint channel program with the University of Arizona.
